CQB Fluoroplastic Magnetic Pump

  • >=10 Sets
    $800.00
Horsepower:
0.01~50KW
Maximum Flow Rate:
100m3/h
Maximum Head:
50m
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 5 Negotiable
Customization:
Customized logo (Min. Order: 10 Sets)
Customized packaging (Min. Order: 10 Sets)

More

Graphic customization (Min. Order: 10 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Sureway
Model Number:
CQB
Structure:
Leak free pump
Usage:
Corrosive fluids, harmful fluids
Power:
30W~50000W
Fuel:
Electrcity
Pressure:
0.1~5bar
Supply Ability
Supply Ability:
100 Set/Sets per Week
Packaging & Delivery
Packaging Details
Plywood box
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 5 To be negotiated
Product Description

CQB Fluoroplastic Magnetic Drive Pump

Leakproof Design
Shaft seal not applied, and indirectly driven by magnetic coupl­ing to completely get away from leaking and site pollution.
The components in contact with flow are made of fluoroplastic alloy to continuously deliver the corrosive medium without any dam­age, such as acid, alkali and strong oxidizer etc.

Working Principle
Drive unit uses active magnet coupling directly mounted on motor shaft, pump chamber fully enclosed, the impeller carrying magnet on pump shaft indirectly driven by magnetic coupling, thus to feature compact structure, safety and energy conservation.

Durable Pump Body Structure
Although the components in contact with liquid are fluoroplastic, pump casing is metal material to bear the weight of pipeline and the impact of mechanical seal.

Detailed Images

Main application

This product is widely used in the industries of petrochemical, acid and alkali production, non-ferrous smelting, the acid washing in automotive manufacturing, rare earth separation, pesticides, dyest­uff,harmaceuticals, papermaking, electroplating,radio etc.

Service temperature: -20℃~100℃.

Packing & Delivery

Packing by plywood box
